Clipsal Surface Socket 3 Pin 230 Volt AC/240 Volt AC 10 Amp Surface IP2X White

$Clipsal\Clipsal_413E-WE.JPG$

Description

Clipsal Standard Series surface socket is a 3 pin, 10 Amp unit for 230 Volt AC / 240 Volt AC supplies. It has AS/NZS 3112, EU RoHS and REACH listed standards, with terminal capacity for 4 x 2.5 sq-mm or 3 x 4.0 sq-mm conductors.

Key Specifications

Barcode (EAN-13)	3606487687948
SKU	CLI413EWE
Brand	Clipsal

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	3 Pin configuration compatible with Clipsal's 240 Series junction boxes Supports 230 Volt AC / 240 Volt AC, 10 Amp Screw terminal with 4 x 2.5 sq-mm / 3 x 4.0 sq-mm capacity
Standard Pack Size	10
UNSPSC Class	39121400
UOM	EA
Vendor Product	413E-WE
Colour	White
Connection Type	Screw Terminal
Current	10 Amp
Diameter	68 mm
Frequency	50 Hz
IP Rating	IP2X
Height	55 mm
Mounting Centres	52 mm
Material	Plastic
Mounting Method	Surface
Pin Configuration	3 Pin
Please Note	Gloss Finish, 4 Terminals, Without Light Indicator, Wire Stripping Length: 16 mm, Standards: AS/NZS 3112 - EU RoHS - REACH, Warranty: 18 Month
Voltage	230 Volt AC/240 Volt AC
Terminal Capacity	4 x 2.5 sq-mm / 3 x 4.0 sq-mm
Width	88 mm
