Schneider Electronic Sounder & Beacon 70-90 dB @ 1 m 12-48 VAC/DC

chevron-left
loader
Loading...

Description

chevron-down
This Harmony XVB audible buzzer unit is supplied with 12V to 48V AC/DC. This indicating bank buzzer is an accessory designed as an audible and signalling unit for custom assembly. It has a continuous or intermittent signal and its sound acoustic level is adjustable. It is impact resistant, dust resistant, water resistant, corrosion resistant, and vibration resistant thanks to its IP65, making it ideal for operation in harsh environments. 90 dB loud buzzer allows for clear alerting on critical machine statuses even from long distance. It complies with international standards and certifications (CCC, CSA C22-2 No.14, EN/IEC 60947-5-1, EAC, UL 508 standards and NEMA 4X).

Key Specifications

chevron-down
Barcode (EAN-13)
3389110845969
SKU
TEEXVB-C9B
Brand
Schneider
Range Name
XVB
Product Type
Audible Warning Devices

Technical Specifications

chevron-down
Looking for something specific? Search with keywords to help filter your required specifications.
search close

Additional Information

Features
  • Continuous or intermittent buzzer
Standard Pack Size 1
UNSPSC Class 46171600
UOM EA
Vendor Product XVBC9B
Alarm Continuous or intermittent buzzer
Connection Type Screw clamp terminals
Current 15 mA
Dimensions 70 mm Width x 63 mm Height x 70 mm Depth
Sound Level 70-90 dB at 1 mtr
Temperature -25 to 50 deg C
Voltage 12-48 Volt AC/DC
