Connectwell Rail Terminal Block Screwed Clamp 2 Wire 35mm Grey Polyamide 66

$Connectwell\Connectwell_CTS35UN.jpg$

Description

35 mm Feed Through Terminal Blocks are the most Versatile terminals for control, Automation, Instrumentation and Power Distribution applications. A specially designed flexible foot enable easy mounting and dismounting from the DIN rail with the help of screw driver. These Terminal Blocks have marker holding recesses to accept marking tags for circuit identification. Cross connection can be achieved with the aid of shorting links/sleeves and screws.

Key Specifications

SKU	ALSCTS35UN
Brand	Connectwell
Product Type	Rail Terminal Blocks

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	50
UNSPSC Class	39121400
UOM	EA
Vendor Product	CTS35UN
Depth	16 mm
Current Rating	125 Amp
Colour	Grey
Height	64.3 mm/66.7 mm/59.2 mm
Insulation Material	Polyamide 66
Mounting Method	DIN 32/35/35-15
Number of Conductors	2
Number of Levels	1
Terminal Type	Screw Clamp
Rated Surge Voltage	8 kV
Tightening Torque	2.5 Nm
Voltage Rating	1100 Volt
Width	50.5 mm
Wire Strip Length	15 mm
Wire Entry Orientation	Side
Wiring Format	2 Conductor Through
