Cabac Circuit Breaker Lug 70mm 8mm Stud Bi-Metal

$Cabac\Cabac_BL70CB-8.JPG$

Description

Bi-Metal Circuit Breaker Lug, 70 mm, 8 mm Stud, 32 mm Barrel Length, 69 mm Overall Length, 1 Hole, 11.5 mm Inside Diameter, 16 mm Lug Width, 18 mm Lug Length, 4 mm Lug Thickness, 13.2 mm A-F Hex Die, HT-70AL, 2 Crimps, Aluminium/Copper Body, Aluminium/Copper

Key Specifications

Barcode (EAN-13)	9318674307594
SKU	CAABL70CB-8
Brand	Cabac

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Manufactured using friction welding process producing a very strong electrically sound joint Suitable for aluminium conductor and copper circuit breaker terminals Crimp from palm end to force compound into conductor strands Crimping compound in barrel and sealed with cap Crimping positions, AF, clearly marked on barrel
Standard Pack Size	1
UNSPSC Class	39121400
UOM	EA
Vendor Product	BL70CB-8
A-F Hex Die	13.2 mm
Barrel Length	32 mm
Body Material	Aluminium/Copper
Conductive Material	Aluminium/Copper
Conductor Size	70 mm
Crimping Die	HT-70AL
Inside Diameter	11.5 mm
Lug Length	18 mm
Lug Thickness	4 mm
Lug Width	16 mm
Number of Crimps	2
Number of Holes	1 Hole
Overall Length	69 mm
Stud Size	8 mm
