2.5mm Flat TPS Cable Red/Black/Green/Yellow 500mtr
Loading...
Description
Flat Twin & Earth Cable, 2 Core & Earth, 2.5 mm, Plain Annealed Copper, 450/750 Volt, 7/0.67 mm Strands, 2 mm Nominal Diameter, 2.5 mm Earth Conductor, 12.4 mm x 5.5 mm Overall Diameter, 20 mm Bend Radius, 0.7 mm Insulation Thickness, Conductor Resistance: DC: 7.41 Ohm/km, V-90 PVC Insulation, 3V-90 PVC Sheath, Red Black Green/Yellow Cores, Black Sheath, 90 deg C, AS/NZS 5000.2
Key Specifications
| Barcode (EAN-13) |
9310835900606
|
|---|---|
| SKU |
CBL2.5TEBLK-5
|
| Brand |
Generic
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Standard Pack Size | 500 |
|---|---|
| UNSPSC Class | 26121600 |
| UOM | MTR |
| Vendor Product | 20200003 |
