CCG Metal Cable Gland Unarmoured General Purpose M20 11-14.5mm Polyester Encapsulated Brass IP66/67/68

$CCG\CCG_Posi_Flex.jpg$

Description

Cable Gland Metal Unarmoured General Purpose, M20, 15 mm Thread Length, 11 mm Min. Sheath OD, 14.5 mm Max. Sheath OD, For Use With Unarmoured Cables, 34 mm Width Across Flats, 36.5 mm Width Across Corners, 13.5 Nm Torque Rating, IP66/67/68, Polyester Encapsulated Brass Body, Thermoplastic Elastomer Seal, -30 to 130 deg C, 47 mm Overall Length

Key Specifications

SKU	CCG053801
Brand	CCG
Range Name	Posi-Flex

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	For use in highly corrosive areas Seals the cable sheath to IP66/68 Specially formulated elastomeric seals Brass parts are encapsulated in a non-corrosive body Marine grade electroless nickel plated entry threads Complete with a thread sealing gasket
Standard Pack Size	24
UNSPSC Class	39121400
UOM	EA
Vendor Product	053801
For Use With	Unarmoured Cables
IP Rating	IP66/67/68
Body Material	Polyester Encapsulated Brass
Max. Sheath OD	14.5 mm
Min. Sheath OD	11 mm
Overall Length	47 mm
Temperature	-30 to 130 deg C
Thread Length	15 mm
Seal Material	Thermoplastic Elastomer
Width Across Corners	36.5 mm
Torque Rating	13.5 Nm
Thread Size	M20
Width Across Flats	34 mm
