CLA IR Motion Sensor Adjustable Surface Mounted 120deg IP66 Black

Description

IR Motion Sensor, Sensing Range: 12 mtr, Sensing Beam: 120 deg, Response Time: Min: 10 sec +/-3 sec; Max: 30 min +/-2 min, 220-240 Volt, Wattage: HAL: 2000 Watt, CFL: 1000 Watt, LED: 1000 Watt, Frequency: 50/60 Hz, Lux: 3-2000 lx, 1.8-2.5 mtr Mounting Height, Switching Function: Manual Override, Mounting Method: Surface, IP66, Material: PC, Black, Dimensions: 115mm Length x 73mm Width x 146mm Depth, Temperature:-20 to 40 deg C

Key Specifications

Barcode (EAN-13)	9326191030673
SKU	CLLSENS008
Brand	CLA
Product Type	Sensors

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	UV resistant
Standard Pack Size	1
UNSPSC Class	39121800
UOM	EA
Vendor Product	SENS008
Colour	Black
Dimensions	115 mm Length x 73 mm Width x 146 mm Depth
Frequency	50/60 Hz
IP Rating	IP66
Lux	3-2000 lx
Mounting Height	1.8-2.5 mtr
Mounting Method	Surface
Material	PC
Response Time	Min: 10 sec +/-3 sec - Max: 30 min +/-2 min
Sensing Beam	120 deg
Switching Function	Manual Override
Sensing Range	12 mtr
Temperature	-20 to 40 deg C
Voltage	220-240 Volt
Wattage	HAL: 2000 Watt / CFL: 1000 Watt / LED: 1000 Watt
