CMP Products Cable Gland Industrial M20 9-14mm Nylon/Polyamide IP66/67/68/69K

$CMP_Products\CMP_20TSPV02TN1L.JPG$

Description

Cable Gland Industrial, M20, 15 mm Thread Length, 9 mm Min. Sheath OD, 14 mm Max. Sheath OD, 24 mm Width Across Flats, IP66/67/68/69K, Nylon/Polyamide Body, CMP SOLO LSF Halogen-Free Thermoset Elastomer Seal, -40 to 100 deg C, Comes with washer and nut

Key Specifications

Barcode (EAN-13)	5052625272305
SKU	CMP20TSPV02TN1L
Brand	CMP Products

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Halogen and phosphorus free. Extremely flame retardant and self-extinguishing according to UL94 V-0. Incorporates CMP's trusted SOLO technology 3rd party certified to IEC/EN 62444 Finger-locking seal provides superior cable retention and strain relief Low weight with high stiffness and strength
Standard Pack Size	1
UNSPSC Class	39121400
UOM	EA
Vendor Product	20TSPV02TN1L
Body Material	Nylon / Polyamide
Max. Sheath OD	14 mm
IP Rating	IP66/67/68/69K
Min. Sheath OD	9 mm
Please Note	Comes with washer and nut
Seal Material	CMP SOLO LSF Halogen-Free Thermoset Elastomer
Temperature	-40 to 100 deg C
Thread Length	15 mm
Thread Size	M20
Width Across Flats	24 mm
