CMP Products Hazardous Area Cable Gland Unarmoured 17-26.3mm M32 IP66/67/68

Description

Hazardous Area Cable Gland, Unarmoured, M32, 15 mm Thread Length, 17 mm Min. Sheath OD, 26.3 mm Max. Sheath OD, 41 mm Width Across Flats, 45.1 mm Width Across Corners, For: All Types of Unarmoured Cable, Exdb, Exeb, Ex nRc, Ex ta, 36.2 mm Protrusion Length, IP66/67/68, Thermoset Elastomer Seal, Brass Body, Nickel Plated Finish, 51.2 mm Overall Length, -60 to 130 deg C

Key Specifications

Barcode (EAN-13)	5052625250945
SKU	CMP32A2F100HC321RA5
Brand	CMP Products
Product Type	Cable Glands Hazardous Area

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Flameproof displacement seal protects the equipment in the event of an explosion Includes a hose connection facility to securely attach protective hose with a cable housed within, the cable is then securely sealed using a CMP displacement seal For use in group I and II mining and non-mining applications, including QLD and NSW coal mining Manufactured from high quality durable materials to prevent corrosion in mining environments For all types of unarmoured cable and enclosed within hose for mechanical protection
Standard Pack Size	1
UNSPSC Class	39121400
UOM	EA
Vendor Product	32A2F100HC321RA5
Body Material	Brass
For Use With	Unarmoured Cable
Finish	Nickel Plated
Hazardous Area Rating	Exdb Exeb Ex nRc Ex ta
IP Rating	IP66/67/68
Max. Sheath OD	26.3 mm
Min. Sheath OD	17 mm
Overall Length	51.2 mm
Protrusion Length	36.2 mm
Seal Material	Thermoset Elastomer
Temperature	-60 to 130 deg C
Thread Length	15 mm
Thread Size	M32
Width Across Flats	41 mm
Width Across Corners	45.1 mm
