CMP Products Breather/Drain Plug Explosive Atmosphere M20 Brass Exe IIC Gb Ex ta IIIC Da

$CMP_Products\CMP_781_Breather_Drains.jpg$

Description

Breather/Drain Plug, Explosive Atmosphere, Gland Size M20, 15 mm Thread Length, 1.5 mm Pitch, Exe IIC Gb, Ex ta IIIC Da, 30 mm Width Across Flats, 33 mm Width Across Corners, 7 N/m, IP66, Brass Body, -60 to 130 deg C, 12.7 mm Protrusion Length

Key Specifications

Barcode (EAN-13)	5052625133187
SKU	CMP781EM25
Brand	CMP Products
Product Type	Hazardous Area Accessories

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Drains equipment susceptible to moisture collection Enables equipment to breathe
Standard Pack Size	1
UNSPSC Class	39121400
UOM	EA
Vendor Product	781EM25
Cable Gland Size	M20
IP Rating	IP66
Hazardous Area Rating	Exe IIC Gb/Ex ta IIIC Da
Protrusion Length	12.7 mm
Temperature	-60 to 130 deg C
Thread Length	15 mm
Thread Pitch	1.5 mm
Width Across Corners	33 mm
Width Across Flats	30 mm
Torque Rating	7 Nm
