Helukabel Thermflex 180 EWKF High Temperature Flexible Cable 2 Core & Earth 2.5mm 0.3/0.5kV Silicone Black

Description

Flexible Cable, Double Insulated, High Temperature 2 Core & Earth, 2.5 mm, Class 5 Stranded Tinned Copper, 0.3/0.5 kV, 10.4 mm Overall Diameter, Bend Radius: Static - 41.6 mm Flexible - 78 mm, Silicone Rubber Insulation, Silicone Rubber Sheath, Blue Brown Green/Yellow Cores, Black Sheath, Fixed - -60 to 180 deg C, Flexible - -25 to 180 deg C

Key Specifications

SKU	DKS75009
Brand	Helukabel
Product Type	Flexible Cable High Temperature Double Insulated

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Flame retardant Halogen free
Standard Pack Size	1
UNSPSC Class	26121600
UOM	MTR
Vendor Product	75009
Bend Radius	Static: 41.6 mm - Flexible: 78 mm
Conductor Type	Class 5 Stranded Copper
Conductor Size	2.5 mm
Core Colours	Brown/Blue/Green/Yellow
Insulation Material	Silicone Rubber
Number of Cores	2 Core + Earth
Overall Diameter	10.4 mm
Sheath Material	Silicone Rubber
Sheath Colour	Black
Temperature	Fixed: -60 to 180 deg C Flexible: -25 to 180 deg C
Voltage	0.3-0.5 kV
