Eaton Residual Current Operated Circuit Breaker 3 Pole+N 20 Amp 240/415V AC 10 kA DIN Rail

$Eaton\Eaton_MRBM4-203C003-A.jpg$

Description

Residual Current Operated Circuit Breaker, 20 Amp, 240/415 Volt AC, 50 Hz, Interrupt Capacity: 10 kA, Trip Sensitivity: 30 mA, Number of Poles: 3P + N, Trip Characteristic: C Curve, Open Mouthed/Lift Terminals Terminal Connection, IP20, IP40, DIN Rail,-35 to 60 deg C, 80mm Height, 70mm Width, 60mm Depth

Key Specifications

Barcode (EAN-13)	4015081660841
SKU	EATMRBM4-20/3/C/003A
Brand	Eaton
Product Type	Residual Current Circuit Breakers

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Four module line-voltage independent RCBO Fits on existing chassis Complete with 950mm long pigtail Type A both AC and pulsating DC
Standard Pack Size	1
UNSPSC Class	39121600
UOM	EA
Vendor Product	MRBM4-20/3/C/003-A
Current	20 Amp
Depth	60 mm
Height	80 mm
Interrupt Capacity	10 kA
Frequency	50 Hz
IP Rating	IP20/40
Mounting Method	DIN Rail
Number Of Poles	3 Pole
Temperature	-35 to 60 deg C
Terminal Connection	Open Mouthed / Lift Terminals
Trip Characteristic	C Curve
Trip Sensitivity	30 mA
Width	70 mm
Voltage	240-415 Volt
