IPD HRC Fuse Link 2 Hole Fixing Bolt In Offset Motor Rated32M50 Amp 660VAC/460VDC 80 kA Class gG BS88 Type A2

Description

Fuse Link HRC 2 Hole Fixing Bolt In Offset Motor Rated, 660 VAC/460 VDC, 32M50 Amp, Class gG, Interrupt Capacity: 80 kA at 660 VAC, 40 kA at 460 VAC, 73mm Fixing Centres, Bolt In Offset Motor Rated Tag, 23.8mm Diameter x 85.8mm Length, BS88 Type A2

Key Specifications

Barcode (EAN-13)	5050096002995
SKU	EEFTIA32M50
Brand	IPD
Range Name	Red Spot
Product Type	Fuse Links HRC

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	For use with RS32, RSM63 and RS63 holders Fault current limitation, distribution/cable protection, equipment/switchgear protection, motor/starter protection
Standard Pack Size	10
UNSPSC Class	39121600
UOM	EA
Vendor Product	TIA32M50
Fixing Centres	73mm
Dimensions	23.8mm Diameter x 85.8mm Length
Current	50 Amp
Interrupt Capacity	80 kA
Standard Reference	BS88 Type A2
Tag Type	Bolt In Offset Motor Rated
Utilisation Category	Class gG
Voltage	660 Volt AC/460 Volt DC
