IPD Fuse Link HRC Bolt In Offset 80 Amp 415VAC/250VDC 80 kA at 415VAC 40 kA at 250VDC Class gG BS88 Type A3
Loading...
Description
Fuse Link HRC Bolt In Offset, 415 VAC/250VDC, 80 Amp, Class gG, Interrupt Capacity: 80 kA at 415 VAC, 40 kA at 250 VDC, 73mm Fixing Centres, Bolt In Offset Tag, 23.8mm Diameter x 85.8mm Length, BS88 Type A3
Key Specifications
| Barcode (EAN-13) |
9322017199326
|
|---|---|
| SKU |
EEFTIS80L
|
| Brand |
IPD
|
| Range Name |
Red Spot
|
| Product Type |
Fuse Links HRC Bolt In
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Features |
|
|---|---|
| Standard Pack Size | 10 |
| UNSPSC Class | 39121600 |
| UOM | EA |
| Vendor Product | TIS80L |
| Fixing Centres | 73 mm |
| Dimensions | 23.8 mm Diameter x 85.8 mm Length |
| Current | 80 Amp |
| Interrupt Capacity | 80 kA |
| Standard Reference | BS88 Type A3 |
| Tag Type | Bolt In Offset |
| Utilisation Category | Class gG |
| Voltage | 415 Volt AC/250Volt DC |
