Electra 0.75 mm Fire Rated Cable X-HF-110/HF-110-TP Red 1mtr
Loading...
Description
Fire Rated Cable, 0.75 mm, Annealed Copper, 0.6-1 kV, 3 Core, 10.1 mm Overall Diameter, 1 mtr Length, 0.6 mm Insulation Thickness, 1.3 mm Sheath Thickness, Red/White Core, X-HF-110 Insulation, HF-110-TP Sheath, Red Sheath, WS52W, 110 deg C, AS/NZS 3013:2005 WS52W IEC 60332 BS 6387
Key Specifications
| SKU |
ELCFRC3075-RED
|
|---|---|
| Brand |
Electra
|
| Product Type |
Fire Rated Cable
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Standard Pack Size | 1 |
|---|---|
| UNSPSC Class | 26121600 |
| UOM | MTR |
| Vendor Product | FRC3075-RED |
| AS3013 Rating | WS52W |
| Conductor Size | 0.75 mm |
| Conductor Type | Annealed Copper |
| Core Colours | Red/White |
| Insulation Material | X-HF-110 |
| Insulation Thickness | 0.6 mm |
| Number of Cores | 3 Core |
| Overall Diameter | 10.1 mm |
| Sheath Colour | Red |
| Sheath Material | HF-110-TP |
| Standards | AS/NZS 3013:2005 WS52W IEC 60332 BS 6387 |
| Sheath Thickness | 1.3 mm |
| Temperature | 110 deg C |
| Voltage | 0.6-1 kV |
Downloads
