Electra 6 mm Fire Rated Cable X-HF-110/HF-110-TP Orange 1mtr

Description

Fire Rated Cable, 6 mm, Class 5 Annealed Copper, 0.6-1 kV, 56 Amp, 4 Core + Earth, 2.5 mm Earth Conductor, 18.2 mm Overall Diameter, 1 mtr Length, 365 mm Bend Radius, 0.7 mm + 0.7 mm Earth Insulation Thickness, 1.8 mm Sheath Thickness, Red/White Core, X-HF-110 Insulation, HF-110-TP Sheath, Orange Sheath, WS52W, AS/NZS 3013:2005 AS/NZS 5000.1:2005 IEC 60332-3 IEC 60332.3.24

Key Specifications

SKU	ELCFRC4060E-ORE
Brand	Electra
Product Type	Fire Rated Cable

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	1
UNSPSC Class	26121600
UOM	MTR
Vendor Product	FRC4060E-ORE
AS3013 Rating	WS52W
Bend Radius	365 mm
Conductor Size	6 mm
Conductor Type	Class 5 Annealed Copper
Core Colours	Red/White
Current	56 Amp
Earth Conductor Size	2.5 mm
Insulation Material	X-HF-110
Insulation Thickness	0.7 mm + 0.7 mm Earth
Number of Cores	4 Core + Earth
Overall Diameter	18.2 mm
Sheath Colour	Orange
Sheath Material	HF-110-TP
Standards	AS/NZS 3013:2005 AS/NZS 5000.1:2005 IEC 60332-3 IEC 60332.3.24
Sheath Thickness	1.8 mm
Voltage	0.6-1 kV
