Flexible Cable 1 Core 16mm 0.6/1KV Copper XLPE Orange

Description

Flexible Cable, 16 mm, Annealed Copper, 0.6-1 kV, 1 Core, 126/0.39 mm Strands, 9.7 mm +/-10% Overall Diameter, 150 mm Bend Radius, 0.7 mm Insulation Thickness, 1.4 mm Sheath Thickness, X-90 XLPE Insulation, TP-90 XLPE Sheath, Orange Sheath, 90 deg C, AS/NZS 5000.1 AS/NZS 1125 IEC 60228 AS/NZS 3808

Key Specifications

SKU	ELCFXLPE1160
Brand	Electra
Product Type	Flexible Cable

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	1
UNSPSC Class	26121500
UOM	MTR
Vendor Product	FXLPE1160
Bend Radius	150 mm
Conductor Size	16 mm
Conductor Type	Annealed Copper
Insulation Material	X-90 XLPE
Insulation Thickness	0.7 mm
Number of Cores	1 Core
Overall Diameter	9.7 mm +/-10%
Sheath Colour	Orange
Sheath Thickness	1.4 mm
Sheath Material	TP-90 XLPE
Standards	AS/NZS 5000.1 AS/NZS 1125 IEC 60228 AS/NZS 3808
Temperature	90 deg C
Stranding	126/0.39 mm
Voltage	0.6-1 kV
