Electra Marine Cable 2 Core 4.65mm 37/0.4mm 100VDC/32VAC Copper V-75 PVC/4V-75 PVC White

Description

Marine Cable, 4.65 mm, Tinned Annealed Copper, 32 Volt AC/100 Volt DC, 50 Amp, 2 Core, 37/0.4 mm Strands, 10 mm x 6 mm Overall Diameter, 0.8 mm Insulation Thickness, 4 Ohm/km Conductor Resistance, Red/Black Core, V-75 PVC Insulation, V-75 PVC Sheath, White Sheath, AS/NZS 1125 AS/NZS 3808

Key Specifications

SKU	ELCMAR621-100
Brand	Electra
Product Type	Marine Cable

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	100
UNSPSC Class	26121800
UOM	MTR
Vendor Product	MAR621-100
Conductor Resistance	4 Ohm/km
Conductor Size	4.65 mm
Conductor Type	Tinned Annealed Copper
Current	50 Amp
Core Colours	Black/Red
Insulation Material	V-75 PVC
Insulation Thickness	0.8 mm
Number of Cores	2 Core
Overall Diameter	10 mm x 6 mm
Sheath Colour	White
Sheath Material	V-75 PVC
Standards	AS/NZS 1125 AS/NZS 3808
Stranding	37/0.4 mm
Voltage	32 Volt AC/100 Volt DC
