Eldon Cable Gland General Purpose EPDM M50 27-35mm IP67

Description

Cable Gland, General Purpose, M50, 27 mm Min. Sheath OD, 35 mm Max. Sheath OD, 50.5 mm Cutout Diameter, 60.5 mm External Diameter, IP67, EPDM Body, -40 to 110 deg C

Key Specifications

Barcode (EAN-13)	8713574187368
SKU	ELDCED50
Brand	Eldon
Product Type	Cable Glands Non-Metal

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Easily installed and economically priced Chemical and oil resistant Excellent insulation and mechanical properties Suitable for holes in materials of 0.5 to 4 mm thickness Made from one piece EPDM and halogen free
Standard Pack Size	1
UNSPSC Class	39121400
UOM	EA
Vendor Product	CED50
Body Material	EPDM
IP Rating	IP67
Max. Sheath OD	35 mm
Min. Sheath OD	27 mm
Temperature	-40 to 110 deg C
Thread Size	M50
