Elcon 16mm 1 Core Black High Temperature Flexible Wire Double Insulated X-HF-110/PVC

$Elcon\Elcon_CHF-LHDN.jpg$

Description

Flexible Wire, High Temperature, Double Insulated, 16 mm, Class 5 Annealed Copper, 0.6-1 kV, 130 Amp, 1 Core, 9.2 mm Overall Diameter, 36.8 mm Static/55.2 mm Flexible Bend Radius, 0.7 mm Insulation Thickness, 1.2 mm Sheath Thickness, DC: 1.21 MOhm/m Insulation Resistance, X-HF-110 Insulation, Nitril Modified PVC (NBR) Sheath, Black Sheath, 110 deg C

Key Specifications

SKU	ELNCHF-LHDN16BM
Brand	Elcon Cables

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	RoHS Compliant Excellent Flexibility Flame retardant Low flame propagation 99.9% OFHC (Oxygen Free High Conductivity) copper which does not show any brittleness
Standard Pack Size	100
UNSPSC Class	26121600
UOM	MTR
Vendor Product	CHF-LHDN16BM
Bend Radius	Static 36.8 mm - Flexible 55.2 mm
Conductor Type	Class 5 Annealed Copper
Conductor Size	16 mm
Current	130 Amp
Insulation Material	X-HF-110
Number of Cores	1 Core
Insulation Resistance	DC: 1.21 Mohm/m
Overall Diameter	9.2 mm
Insulation Thickness	0.7 mm
Sheath Material	Nitrile Modified PVC (NBR)
Sheath Colour	Black
Sheath Thickness	1.2 mm
Temperature	110 deg C
Voltage	0.6-1 kV
