Elcon Cables Fig8 Solar Cable 2 Core 25mm 0.6/1kV XLPE/XLPE Black Flame Retardant

Description

Fig8 Solar Cable 2 Core, 25 mm, Tinned Copper, 0.9/1.8 kV DC, 0.6/1 kV AC, 2 Cores, Electron Beam XLPE Insulation, Electron Beam XLPE Sheath, Red/Black Core Colours, Black Sheath, 120 deg C

Key Specifications

SKU	ELNCSO-F8TUV25BM
Brand	Elcon Cables
Product Type	Solar Cable Figure 8

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Excellent flexibility, Ezi tear webbing Flame retardant, 120 deg C low smoke zero halogen UV stabilised TUV Rheinland approved Metre marked Compact design
Standard Pack Size	1
UNSPSC Class	26121600
UOM	MTR
Vendor Product	F8TUV25BM
Conductor Size	25 mm
Conductor Material	Tinned Copper
Insulation Material	Electron Beam XLPE
Number of Cores	2 Core
Sheath Colour	Black
Sheath Material	Electron Beam XLPE
Voltage	0.9-1.8 kV DC/0.6-1 kV AC
Temperature	120 deg C
