Elko Contactor General Purpose AC3 40A 230VAC/DC 4NC 3 Pole DIN Rail/Panel Mount

Description

General Purpose Contactor, 230 Volt AC/DC Coil Voltage, 40 Amp AC3 AC3 Rating, 40 Amp AC1 AC1 Rating, 4 Normally Closed Configuration, 4 Pole, 3 Phase Phase, DIN Rail/Panel Mounting, IP20, -5 to 55 deg C, 84 mm Height, 53.3 mm Width, 60 mm Depth

Key Specifications

Barcode (EAN-13)	8595188121484
SKU	ELOVS440-04
Brand	Elko
Product Type	Contactors General

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	For VS425, VS440, VS463, an auxiliary contact VSK-11 or VSK-20 can be mounted on the side of the module
Standard Pack Size	1
UNSPSC Class	39121500
UOM	EA
Vendor Product	VS440-04/230V
AC1 Rating (Amps)	40 Amp AC1
Contact Configuration	4 Normally Closed
AC3 Rating (Amps)	40 Amp AC3
IP Rating	IP20
Depth	60 mm
Height	84 mm
Mounting Method	DIN Rail/Panel
Number Of Poles	4 Pole
Operating Coil Voltage	230 Volt AC/DC
Phase	3 Phase
Temperature	-5 to 55 deg C
Width	53.3 mm
