Enphase IQ8HC Microinverter 384VA Single & Three Phase MC4 DC Bulkhead

$Enphase\Enphase_IQ8HC-72-M-INT.JPG$

Description

Solar Microinverter, 1/Multi Phase Phase, 505 Watt DC Input, 37 Volt DC Input, 18-49 Volt DC Operating Voltage, 29.5-45 Volt DC MPPT Voltage Range, 22 Volt DC Start-up, 14 Amp DC Max. Input, 380 VA AC Output, 384 VA AC Max. Apparent, 50 Hz, 1.65 Amp AC Output, 1 (0.8 Leading-0.8 Lagging) Power Factor, <5% Total Harmonic Distortion, 0.974 Efficiency, 0.968 European Weighted Efficiency, Isolated (HF Transformer), <2600 mtr Max. Altitude, Natural Convection Cooling, AC: IQ Cabling/DC: Staubli MC4 Connection, IP67, -40 to 60 deg C

Key Specifications

SKU	ENPIQ8HC-72-M-INT
Brand	Enphase
Product Type	Solar Microinverter

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Compatible with latest-generation high-output PV modules Easy to install and commission High-energy production, reliability and safety
Standard Pack Size	1
UNSPSC Class	26111600
UOM	EA
Vendor Product	IQ8HC-72-M-INT
AC Max. Apparent Power	384 VA
AC Operating Frequency	50 Hz
AC Output Power	380 VA
Connection Type	AC: IQ Cabling/DC: Staubli MC4
AC Output Current	1.65 Amp
Cooling Method	Natural Convection
DC Input Power	505 Watt
DC Input Voltage	37 Volt
DC Operating Voltage	18-49 Volt
DC MPPT Voltage Range	29.5-45 Volt
DC Start-up Voltage	22 Volt
DC Max. Input Current	14 Amp
Depth	30.2 mm
Efficiency	0.974
European Weighted Efficiency	0.968
Height	212 mm
IP Rating	IP67
Max. Operating Altitude	<2600 mtr
Operating Temperature	-40 to 60 deg C
Power Factor	1 (0.8 Leading-0.8 Lagging)
Relative Humidity	4-100% (Condensing)
Topology	Isolated (HF Transformer)
Total Harmonic Distortion	<5%
Width	175 mm
