FantechTrade Roof Mounted Exhaust Fan Vertical Discharge 400mm 2.2 Amp 0.49 kW 3460 cu-m/hr 56-54 dBA at 3m 23 rps Grey

$FantechTrade\FantechTrade_Gamma_Series.jpg$

Description

Roof Mounted Exhaust Fan, Fan Size: 400mm, 220/240 Volt AC, 2.2 Amp, 0.49 kW, 50 Hz, Phase: 1 Phase, Air Flow Rate (cu-m/hr): 3460 cu-m/hr, Air Flow Rate (l/sec): 961 l/sec, 56-54 dBA at 3m, Speed: 23 rps, IP44, Motor Type: Squirrel Cage Induction, Roof Mounting, 1K, 2K, 4K, 8K, UV-Stabilised Plastic, Grey, 417mm Height, 640mm Dia

Key Specifications

Barcode (EAN-13)	9325971001629
SKU	FANCE404V
Brand	FantechTrade
Product Type	Exhaust fans

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Robust, lightweight construction Cowls are U.V. Stabilised Compact, low profile design Can be used in ducted Systems Can be mounted at angles up to 30 deg Twin fan units to give 100% stand-by capacity can be provided for vertical discharge arrangement in a limited range of sizes Backdraft dampers are an optional extra with single fan units and standard supply with twin fan units. The pressure loss must be added to the System pressure when making selections
Standard Pack Size	1
UNSPSC Class	40101600
UOM	EA
Vendor Product	CE404V
Air Flow Cubic Meters per Hour	3460 cu-m/hr
Air Flow Litres per Second	961 l/sec
Colour	Grey
Current	2.2 Amp
Diameter	640 mm
Fan Size	400 mm
Frequency	50 Hz
Height	417 mm
IP Rating	IP44
Motor Type	Squirrel Cage Induction
Material	UV-Stabilised Plastic
Phase	1 Phase
Mounting Method	Roof
Sound Level	56-54 dBA at 3 mtr
Speed	23 rps
Voltage	220-240 Volt
Wattage	0.49 kW
