Garland RG59B/U Coaxial Cable 75Ohm 0.28mm 1/0.6mm Polyethylene/LSHF Black

$Garland\Garland_CC59HF500.jpg$

Description

RG59B/U Coaxial Cable, 0.28 mm, Bare Copper, 0.6mm Conductor Diameter, Bend Radius: Install: 62mm, Tensile Strength: Before Aging >12 MPa, Stranding: 1/0.6mm, Insulation Thickness: 1.5mm, Sheath Thickness: 1mm, Conductor Resistance: DC: 62 Ohm/km at 20 deg C, 75 +/-3 Ohm Impedance, Bare Copper 84% Coverage Braid, Solid Polyethylene Insulation, LSHF Sheath, Black Sheath, 6.2mm Overall Diameter,-250 to 900 deg C

Key Specifications

Barcode (EAN-13)	9329849013714
SKU	GARCC59HF500
Brand	Garland
Product Type	Coax Cable

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	500
UNSPSC Class	43221700
UOM	MTR
Vendor Product	CC59HF500
Bend Radius	Install: 62 mm
Braid Material	Bare Copper 84% Coverage
Conductor Resistance	DC: 62 Ohm/km at 20 deg C
Conductor Diameter	0.6 mm
Conductor Size	0.28 mm
Conductor Type	Bare Copper
Insulation Thickness	1.5 mm
Overall Diameter	6.2 mm
Insulation Material	Solid Polyethylene
Sheath Thickness	1 mm
Sheath Colour	Black
Temperature	-250 to 900 deg C
Sheath Material	LSHF
Stranding	1/0.6 mm
Tensile Strength	Before Aging >12 MPa
