Garland 0.44mm 6 Core Grey Security Cable PVC/PVC

Description

Security Cable, 0.44 mm, Annealed Copper, 6 Core, 14/0.2 mm Strands, 6.1 mm Overall Diameter, 61 mm Static Bend Radius, 0.3 mm Insulation Thickness, 0.65 mm Sheath Thickness, Insulation: >100% Outer Sheath: >100% Elongation, 166 N Pulling Tension, Before Aging: >12 MPa Tensile Strength, 45.2 Ohm/km Conductor Resistance, 50 MOhm/km Insulation Resistance, PVC Insulation, PVC Sheath, Grey Sheath, -15 to 70 deg C, AS/ACIF S008 BS3737-3.30 AS 1049

Key Specifications

Barcode (EAN-13)	9329849005399
SKU	GARMC146GY250B
Brand	Garland
Product Type	Security Cable

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	250
UNSPSC Class	26121600
UOM	MTR
Vendor Product	MC146GY250B
Bend Radius	Static 61 mm
Conductor Size	0.44 mm
Conductor Resistance	45.2 Ohm/km
Conductor Type	Annealed Copper
Elongation	Insulation: >100% Outer Sheath: >100%
Insulation Material	PVC
Insulation Thickness	0.3 mm
Insulation Resistance	50 MOhm/km
Overall Diameter	6.1 mm
Number of Cores	6 Core
Pulling Tension	166 N
Sheath Colour	Grey
Sheath Material	PVC
Standards	AS/ACIF S008 BS3737-3.30 AS 1049
Sheath Thickness	0.65 mm
Stranding	14/0.2 mm
Temperature	-15 to 70 deg C
Tensile Strength	Before Aging: >12 MPa
