Hager Combination RCD Circuit Breaker RCBO 1Pole 32 Amp 240V AC 6 kA 1Module 17.5mm DIN Rail

Description

Combination RCD Circuit Breaker RCBO Type A, 32 Amp, 240 Volt AC, 50 Hz, Interrupt Capacity: 6 kA, Trip Sensitivity: 30 mA, Number of Poles: 1, Number of Modules: 1, 17.5mm Module Width, Trip Characteristic: C Curve, 1/10 mm Flexible, 1/16 mm Rigid Terminal Connection, Screw, IP20, DIN Rail,-25 to 80 deg C, 92mm Height, 17.7mm Width, 70mm Depth

Key Specifications

Barcode (EAN-13)	3250611069560
SKU	HAGADC332T
Brand	Hager
Range Name	onekombo
Product Type	Combination RCBO

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	1
UNSPSC Class	39121600
UOM	EA
Vendor Product	ADC332T-NLA
Depth	70 mm
Connection Type	Screw
Height	92 mm
Current	32 Amp
Frequency	50 Hz
Interrupt Capacity	6 kA
IP Rating	IP20
Modules	1 Module 17.5 mm
Mounting Method	DIN Rail
Number Of Poles	1 Pole
Temperature	-25 to 80 deg C
Terminal Connection	1 / 10 sq-mm Flexible / 1 / 16 sq-mm Rigid
Trip Characteristic	C Curve
Trip Sensitivity	30 mA
Voltage	240 Volt
Width	17.7 mm
