Hager Miniature Circuit Breaker D Curve 40Amp 6kA 1Pole 1Module DIN Rail Mount

Description

Miniature Circuit Breaker D Curve, 240/415 Volt AC, 40 Amp, Interrupt Capacity: 6 kA, Number of Modules: 1, Number of Poles: 1, Trip Characteristic: D Curve, 2.8 N/m Tightening Torque, Screw Terminal, IP20, 4000 Cycles, 1 to 25 mm Flexible/1 to 35 mm Rigid Cable, DIN Rail, 30 deg C, 84.6mm Height x 17.7mm Width x 70mm Depth

Key Specifications

Barcode (EAN-13)	3250614353031
SKU	HAGMDN140P
Brand	Hager
Product Type	Mini Circuit Breakers

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	1
UNSPSC Class	39121600
UOM	EA
Vendor Product	MDN140P
Cable Size	1-25 sq-mm Flexible / 1-35 sq-mm Rigid
Current	40 Amp
Depth	70 mm
Height	84.6 mm
Interrupt Capacity	6 kA
IP Rating	IP20
Mounting Method	DIN Rail
Number Of Poles	1 Pole
Temperature	30 deg C
Terminal Type	Screw
Tightening Torque	2.8 Nm
Voltage	240-415 Volt
Width	17.7 mm
