IDEC Miniature General Purpose Relay Plug-In Mount 1P SPDT 10A 240V 5 Pin Flat

Description

Miniature General Purpose Relay, 240 Volt AC, 240 Volt AC, 10 Amp, 0.8 Watt, 5 Pin Flat, 1 Pole, SPDT/1CO, 26710 Ohm, Operating Time: 20 Operate/Release ms, Plug-In Mount, Silver Cadmium Oxide/Cadmium Free (Ag-alloy), -25 to 50 deg C, 27.5 mm Height, 42 mm Width, 14 mm Depth

Key Specifications

Barcode (EAN-13)	9322017188108
SKU	IDCRH1B-UAC240
Brand	IDEC
Range Name	RH Series
Product Type	Power Relays

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Compact midget size saves space High switching capacity Without LED
Standard Pack Size	1
UNSPSC Class	39122300
UOM	EA
Vendor Product	RH1B-UAC240
Contact Configuration	SPDT/1 Changeover
Contact Material	Silver Cadmium Oxide/Cadmium Free (Ag-alloy)
Current	10 Amp
Height	27.5 mm
Depth	14 mm
Mounting Method	Plug In
Number Of Poles	1 Pole
Operating Coil Voltage	240 Volt AC
Operating Time	20 Operate/Release ms
Pin Configuration	5 Pin Flat
Temperature	-25 to 50 deg C
Power Rating	0.8 Watt
Resistance	26710 Ohm
Width	42 mm
Voltage	240 Volt AC
