IME AC Ammeter Analogue Moving Iron Current Transformer 0-500A x 5 90Deg 48mm W Panel Mount

Description

AC Ammeter Analogue Moving Iron, 0 to 500 Amp With x 5 Over-Scale, 600 Volt AC, 0-500/2.5 kA, 50/45-65 Hz, Current Transformer, 90 deg Deflection Accuracy Class 1.5, -25 to 50 deg C, Analogue Display, 48 mm Height x 48 mm Width, Panel Mount, Polycarbonate, 45 mm Height x 45 mm Width x 69 mm Depth

Key Specifications

SKU	IMERQ48EACT5A5X500A
Brand	IME
Range Name	RQ48
Product Type	Ammeters

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Accuracy class 1.5 IP52 rated front frame
Standard Pack Size	1
UNSPSC Class	41113600
UOM	EA
Vendor Product	RQ48EACT5A5X500
Current	0-500 Amp/2.5 kA
Depth	69 mm
Display	Analogue
Frequency	50/45-65 Hz
Frame Size	48mm x 48mm
Height	45 mm
Mounting Method	Panel
Operation Form	Current Transformer
Readout Form	90 deg Deflection Accuracy Class 1.5
Scale	0 to 500 Amp with x5 Over-Scale
Temperature	-25 to 50 deg C
Voltage	600 Volt
Width	45 mm
