Lapp Kabel Metal Cable Gland Unarmoured General Purpose Extra Long Thread M12x1.5 1-5mm Nickel Plated Brass IP69

$Lapp_Kabel\Lapp_Kabel_53112105.jpg$

Description

Metal Cable Gland, Unarmoured, General Purpose, Extra Long Thread, M12 x 1.5, 12 mm Thread Length, 1.5 mm Pitch, 1 mm Min. Sheath OD, 5 mm Max. Sheath OD, For Unarmoured Cable, IP69, CR Seal, Brass Body, Nickel Plated Finish, -25 to 100 deg C (Dynamic), -40 to 100 deg C (Fixed), 32 mm Overall Length, 100 Pieces

Key Specifications

SKU	LAP53112105
Brand	Lapp Kabel
Range Name	Skintop MSR-M-XL
Product Type	Cable Glands Unarmoured

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Good chemical resistance Corrosion-resistant Mechanical resistance Optimum strain relief Acid-resistant Temperature-resistant
Standard Pack Size	100
UNSPSC Class	39121400
UOM	EA
Vendor Product	53112105
For Use With	Unarmoured Cable
Finish	Nickel Plated
IP Rating	IP69
Body Material	Brass
Max. Sheath OD	5 mm
Min. Sheath OD	1 mm
Overall Length	32 mm
Temperature	-25 to 100 deg C (Dynamic)/-40 to 100 deg C (Fixed)
Thread Length	12 mm
Seal Material	CR
Thread Pitch	1.5 mm
