Molex PowerCat MOD-Clip Jack CAT6A Shielded RJ45 568A/B Black

$Molex\Molex_MMC-00017-04.jpg$

Description

MOD-Clip Jack, RJ45 Connector, 2.5 mOhm Contact Resistance, >100 MOhm Insulation Resistance, CAT6A Shielded, 568A/B Wiring Scheme, Die Cast Zinc Alloy Housing, 23.1mm Height, 17.8mm Width, 41.3mm Depth

Key Specifications

SKU	MODMMC-00017-04
Brand	Molex

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Robust die cast zinc alloy housing 360 deg shielded Dual color coding allows 568A/B wiring Patented IDC V-shaped contacts that flex not fatigue when terminated Spring-loaded shutter Accepts color coded port identification labels C6A channel performance when installed as a complete PowerCat 6A Shielded System Spring loaded cable/drain wire clamp Cable can be terminated in 3 directions - Straight, on left or right side of jack Complies with ISO/IEC 11801 and TIA Cat 6A channel and PL requirements
Standard Pack Size	1
UNSPSC Class	39121400
UOM	EA
Vendor Product	MMC-00017-04
Cable Type	CAT6A Shielded
Connector Type	RJ45
Depth	41.3mm
Height	23.1mm
Housing Material	Die Cast Zinc Alloy
Width	17.8mm
