NHP Combination RCD Circuit Breaker RCBO 1P+ N 10 Amp 240V AC 6 kA 1Module 18mm DIN 35 Rail

$NHP\NHP_DSRCBSXXXXCAN.jpg$

Description

Residual Current Device, 240 Volt, 10 Amp, 50/60 Hz, 6 kA Interrupt Capacity, 30 mA Trip Sensitivity, C Curve, 1 + N Pole, 1 Module 18 mm, 16 sq-mm/25 sq-mm Flexible/25 sq-mm/35 sq-mm Rigid Terminal, Pin/Fork Connection, IP20/40, DIN Rail Mounting, 5 to 60 deg C, 86 mm Height, 18 mm Width, 76 mm Depth

Key Specifications

Barcode (EAN-13)	5413656948353
SKU	NHPDSRCBS1030CAN
Brand	NHP
Range Name	Din-Safe

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	C curve for general light, power and motor starting applications Type A RCD with switched neutral 30 mA sensitivity for general personnel protection applications 10 mA sensitivity option for higher risk applications Compact single screw RCBO features a neutral pigtail saving cable and installation time Pad lockable and sealable toggle restricts unauthorized action Fast connection pin/fork busbar comb or NC or GB busbar chassis Suits pole-covers, loadcentres and the concept range of panelboards 10 mA units compliant with Type 1 requirements
Standard Pack Size	1
UNSPSC Class	39121600
UOM	EA
Vendor Product	DSRCBS1030CAN-NLA
Depth	76 mm
Connection Type	Pin/Fork
Height	86 mm
Current	10 Amp
Frequency	50/60 Hz
Interrupt Capacity	6 kA
IP Rating	IP20/40
Modules	1 Module 18 mm
Mounting Method	DIN Rail
Number Of Poles	1 Pole
Temperature	5 to 60 deg C
Terminal Connection	16 sq-mm / 25 sq-mm Flexible / 25 sq-mm / 35 sq-mm Rigid
Trip Characteristic	C Curve
Trip Sensitivity	30 mA
Voltage	240 Volt
Width	18 mm
