NHP Din-Safe RCBO Type A 32A 100mA 10kA 400/415V AC 3P+N C Curve IP40/IP20

Description

RCBO, 32 Amp, 100 mA, 400/415 Volt AC, 50/60 Hz, 10 kA Interrupt Capacity, <300 ms Trip Sensitivity, 3P + N, 3 Module, C Curve, IP40/IP20, DIN-35 Rail Mounting,-5 to 40 deg C, 117.5mm Height, 54mm Width, 71.6mm Depth

Key Specifications

SKU	NHPDSRCBT32100A
Brand	NHP
Range Name	Din-Safe
Product Type	Combination RCBO

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	1
UNSPSC Class	39121600
UOM	EA
Vendor Product	DSRCBT32100A
Depth	71.6 mm
Height	117.5 mm
Current	32 Amp/100 mA
Frequency	50/60 Hz
Interrupt Capacity	10 kA
IP Rating	IP40/20
Mounting Method	DIN Rail
Number Of Poles	3 Pole
Temperature	-5 to 40 deg C
Trip Characteristic	C Curve
Trip Sensitivity	<300 ms
Voltage	415-500 Volt
Width	54 mm
