NHP Din-Safe Type A RCBO 3P + N 10kA 63A 100mA C Curve

Description

RCBO, 63 Amp, 400/415 Volt AC, 50/60 Hz, 10 kA Interrupt Capacity, 100 mA Trip Sensitivity, 3P + N, C Curve, IP40 Inside, IP20 Outside, DIN-35 Rail Mounting,-5 to 40 deg C Maximum, 117.5mm Height, 53.4mm Width, 71.6mm Depth

Key Specifications

SKU	NHPDSRCBT63100A
Brand	NHP
Range Name	Din-Safe
Product Type	Combination RCBO

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	1
UNSPSC Class	39121600
UOM	EA
Vendor Product	DSRCBT63100A
Depth	71.6 mm
Height	117.5 mm
Current	63 Amp
Frequency	50/60 Hz
Interrupt Capacity	10 kA
IP Rating	IP40 Inside/IP20 Outside
Mounting Method	DIN Rail
Number Of Poles	3 Pole
Temperature	-5 to 40 deg C Maximum
Trip Characteristic	C Curve
Trip Sensitivity	100 mA
Voltage	400-415 Volt
Width	53.4 mm
