NHP Din-Safe DIN-T Residual Current Circuit Breaker 3P+N 100A 300mA Type A

$NHP\NHP_DSRCD4100300A.jpg$

Description

Residual Current Circuit Breaker, 4000/415 Volt AC, 100 Amp, 50/60 Hz, 500 Amp Interrupt Capacity, 300 mA Trip Sensitivity, 4 Module, 3 Pole + N, Inside: IP40, Outside: IP20, DIN-35 Rail Mounting, 10000 Cycles Electrical Life, 20000 Cycles Mechanical Durability, 1.5-50mm, 1.5-35mm, 5 Nm Tightening Torque,-25 to 55 deg C, 86mm Height x 72mm Width x 76mm Depth

Key Specifications

SKU	NHPDSRCD4100300A
Brand	NHP
Range Name	Din-Safe
Product Type	Residual Current Circuit Breakers

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	DIN-SAFE RCCBs feature 10 kA conditional short circuit rating Fast connection pin/fork busbar comb or busbar chassis Suits pole-covers and loadcentres
Standard Pack Size	1
UNSPSC Class	39121600
UOM	EA
Vendor Product	DSRCD4100300A
Conductor Size	1.5-50mm/1.5-35mm
Current	100 Amp
Frequency	50/60 Hz
Interrupt Capacity	500 Amp
Mechanical Durability	20000 Cycles
IP Rating	IP40 Inside/IP20 Outside
Mounting Method	DIN Rail
Number Of Poles	3 Pole
Temperature	-25 to 55 deg C
Tightening Torque	5 Nm
Trip Sensitivity	300 mA
Voltage	400-415 Volt
