NHP Safety Switch RCCB Type A 3P + NPole 63A 415VAC 100mA 4Module 72mm DIN 35 Rail Mount

$NHP\NHP_DSRCD463100A.jpg$

Description

Safety Switch RCCB Type A, 415 Volt AC, 63 Amp, 50/60 Hz, 100 mA Trip Sensitivity, 4 Modules, 72mm Module Width, 3P + N Poles, Fork/Pin Terminal, IP40 Inside/IP20 Outside, DIN 35 Rail, 10000 Cycles, 20000 Cycles Mechanical Durability, 1.5-35 mm Flexible/1.5-50 mm In/Rigid Conductor Conductor, 5 N/m Top/Bottom Tightening Torque,-25 to 55 deg C, 86mm Height x 72mm Width x 76mm Depth

Key Specifications

SKU	NHPDSRCD463100A
Brand	NHP
Range Name	Din-Safe
Product Type	Safety Switches RCCB

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	DIN-SAFE RCCBs feature 10 kA conditional short circuit rating 1P+N and 3P+N for single or three phase loads Type A, AI, F & B RCD options 30 mA sensitivity featured as standard simplifying the selection for personnel protection applications 100 mA, 300 mA and 500 mA sensitivity options Fast connection pin/fork busbar comb or busbar chassis Suits pole-covers and loadcentres
Standard Pack Size	1
UNSPSC Class	39121600
UOM	EA
Vendor Product	DSRCD463100A
Conductor Size	1.5-35 sq-mm Flexible - 1.5-50 sq-mm In/Rigid Conductor
Depth	76 mm
Frequency	50/60 Hz
Electrical Life	10000 Cycles
IP Rating	IP40/20
Height	86 mm
Mechanical Durability	20000 Cycles
Modules	4 Module 72mm
Mounting Method	DIN Rail
Number Of Poles	3 Pole
Temperature	-25 to 55 deg C
Terminal Type	Fork/Pin
Tightening Torque	5 Nm Top/Bottom
Trip Sensitivity	100 mA
Width	72 mm
