Terasaki DIN-T DIN Contactor 1 Pole 20A 2NO 240VAC/DC Coil

Description

DIN Contactor, 240 Volt AC/DC Coil Voltage, 1.3 kW AC3 AC3 Rating, 9 Amp AC3 AC3 Rating, 20 Amp AC1 AC1 Rating, 2 Normally Opened Configuration, 1 Pole, Screw Terminal, DIN Rail Mounting, IP20, -25 to 55 deg C, 85 mm Height, 17.8 mm Width, 58 mm Depth

Key Specifications

SKU	NHPDTC2020240D
Brand	Terasaki
Range Name	Din-T DTC
Product Type	Contactors DIN

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Silent operated, hum free AC/DC coils Integrated surge protection Low power consumption Indicator position flag red/green Space saving, no spacer required Add on auxiliary contact 2NO or 1NO/1NC
Standard Pack Size	1
UNSPSC Class	39121500
UOM	EA
Vendor Product	DTC2020240D
AC3 Rating (kW)	1.3 kW AC3
AC1 Rating (Amps)	20 Amp AC1
Contact Configuration	2 Normally Opened
AC3 Rating (Amps)	9 Amp AC3
IP Rating	IP20
Depth	58 mm
Height	85 mm
Mounting Method	DIN Rail
Number Of Poles	1 Pole
Operating Coil Voltage	240 Volt AC/DC
Temperature	-25 to 55 deg C
Terminal Connection	Screw
Width	17.8 mm
