NHP MOD6 RCBO 3 Pole+N 6kA 16A 30mA C Curve Type A RCD Pigtail 54mm

$NHP\NHP_M6RCBT1630A.jpg$

Description

Residual Current Device, 400-415 Volt, 16 Amp, 50/60 Hz, 6 kA Interrupt Capacity, 30 mA Trip Sensitivity, C Curve, 3 + N Pole, Fork/Pin Connection, IP20/40, DIN Rail Mounting, 5 to 40 deg C, 117.5 mm Height, 54 mm Width, 71.6 mm Depth

Key Specifications

SKU	NHPM6RCBT1630A
Brand	NHP
Range Name	MOD6

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	M6RCBT MOD6 RCBOs feature 6 kA short circuit rating C-Curve for general light, power and motor starting applications Type A RCD 30 mA sensitivity for general personnel protection applications Compact 3P (54 mm) width space saving Neutral pigtail (900 mm) saving cable and installation time Padlockable and sealable toggle restricts unauthorised action Free tripping mechanism even if toggle is locked or sealed ON or OFF Fast connection pin/fork busbar comb or MOD6 busbar chassis Suits Concept One panelboards
Standard Pack Size	1
UNSPSC Class	39121600
UOM	EA
Vendor Product	M6RCBT1630A
Depth	71.6 mm
Connection Type	Fork/Pin
Height	117.5 mm
Current	16 Amp
Frequency	50/60 Hz
Interrupt Capacity	6 kA
IP Rating	IP20/40
Mounting Method	DIN Rail
Number Of Poles	3 Pole
Temperature	5 to 40 deg C
Trip Characteristic	C Curve
Trip Sensitivity	30 mA
Voltage	400-415 Volt
Width	54 mm
