NHP MOD6 Type A RCBO 3P + N 6kA 63A 30mA C Curve

$NHP\NHP_M6RCBT6330A.jpg$

Description

RCBO, 63 Amp, 400/415 Volt AC, 50/60 Hz, 6 kA Interrupt Capacity, 30 mA Trip Sensitivity, 3P + N, C Curve, IP40 Inside, IP20 Outside, DIN-35 Rail Mounting,-5 to 40 deg C Maximum, 117.5mm Height, 54mm Width, 71.6mm Depth

Key Specifications

SKU	NHPM6RCBT6330A
Brand	NHP
Range Name	MOD6
Product Type	Combination RCBO

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	M6RCBT MOD6 RCBOs feature 6 kA short circuit rating C-Curve for general light, power and motor starting applications Type A RCD 30 mA sensitivity for general personnel protection applications Compact 3P (54mm) width space saving Neutral pigtail (900mm) saving cable and installation time Padlockable and sealable toggle restricts unauthorised action Free tripping mechanism even if toggle is locked or sealed ON or OFF Fast connection pin/fork busbar comb or MOD6 busbar chassis Suits Concept One panelboards
Standard Pack Size	1
UNSPSC Class	39121600
UOM	EA
Vendor Product	M6RCBT6330A
Current	63 Amp
Current	63 Amp
Depth	71.6 mm
Frequency	50/60 Hz
Height	117.5 mm
Interrupt Capacity	6 kA
IP Rating	IP40 Inside/IP20 Outside
Mounting Method	DIN Rail
Number Of Poles	3 Pole
Temperature	-5 to 40 deg C Maximum
Trip Characteristic	C Curve
Trip Sensitivity	30 mA
Voltage	400-415 Volt
Width	54 mm
