NHP MOD6+ RCBO Type A 415 VAC 32 Amp 6 kA 3 Pole + N 30 mA IP40 3 Module 54 mm

$NHP\NHP-MOD6_MD6RT3230A.JPG$

Description

NHP MOD6+ Residual Current Devices (RCDs) offer a 6 kA rating with a proven history in domestic and commercial applications. The MOD6+ RCD range offers many solutions for both 1 phase in 10 mA and 30 mA sensitivities as well as 3 phase in 30 mA sensitivities. The MOD6+ RCDs can be easily installed into NHP Loadcenters, as well as MOD6+ RCBOs into MOD6+ Distribution Panelboards.

Key Specifications

Barcode (EAN-13)	9321807006332
SKU	NHPMD6RT3230A
Brand	NHP
Range Name	MOD6+

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Standard AS/NZS 61009 Approval No. ESV220008 and RCM Earth leakage protection Type A Unswitched neutral Suits MOD6+ Panelboards and M6NC busbar chassis General light and power applications
Standard Pack Size	1
UNSPSC Class	39121600
UOM	EA
Vendor Product	MD6RT3230A
Colour	Grey
IP Rating	IP40
Interrupt Capacity	6 kA
Connection Type	Fork/Pin
Frequency	50/60 Hz
Depth	77.1 mm
Current	32 Amp
Height	117.5 mm
Modules	3 Module 54 mm
Mounting Method	DIN Rail
Number Of Poles	3 Pole
Trip Characteristic	C Curve
Terminal Connection	1-25 sq-mm
Temperature	-5 to 55 deg C
Trip Sensitivity	30 mA
Voltage	415 Volt AC
Width	54 mm
