Nicote Hazardous Area Cable Gland Armoured Barrier 12.5-15.5mm M20 IP66/68

Description

Hazardous Area Cable Gland, Armoured, Barrier, M20, 15.8 mm Thread Length, 1.5 mm Pitch, 12.5 mm Min. Sheath OD, 15.5 mm Max. Sheath OD, 9.75 mm Max. Bedding OD, 0.9 mm Min. Armour Wire, 1.25 mm Max. Armour Wire, 27 mm Width Across Flats, 54 mm Protrusion Length, IP66/68, Brass Body, Nickel Plated Finish

Key Specifications

Barcode (EAN-13)	9318674394921
SKU	NICFLPW203B
Brand	Nicote
Range Name	Type FLPWB
Product Type	Cable Glands Hazardous Area

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Indoor and outdoor use in hazardous areas Provides barrier epoxy seal to cable cores, armour clamp and seal on outer sheath
Standard Pack Size	1
UNSPSC Class	39121400
UOM	EA
Vendor Product	FLPW203B
Body Material	Brass
Finish	Nickel Plated
IP Rating	IP66/68
Protrusion Length	54 mm
Max. Bedding OD	9.75 mm
Max. Sheath OD	15.5 mm
Min. Sheath OD	12.5 mm
Min. Armour Wire	0.9 mm
Max. Armour Wire	1.25 mm
Thread Pitch	1.5 mm
Thread Size	M20
Width Across Flats	27 mm
Thread Length	15.8 mm
