Std Pack Size
1
OUR P/N:
OLX7/085-2ERBBA1
Flat Twin & Earth Cable, 2 Core & Earth, 4 mm, Stranded Copper, 450/750 Volt, 2.5 mm Earth Conductor, 13.9 mm x 6.3 mm Overall Diameter, 0.8 mm Insulation Thickness, 1.1 mm Sheath Thickness, Conductor Resistance: DC: 4.61 Ohm/km, AC: 5.61 Ohm/km, Insulation Resistance: 12 MOhm/km, V-90 PVC Insulation, PVC Sheath, Red Black Green/Yellow Cores, Black Sheath, 90 deg C, AS/NZS 1125, AS/NZS 5000.2
Additional Information
| Brand | Olex |
|---|---|
| Standard Pack Size | 1 |
| UNSPSC Class | 26121600 |
| UOM | MTR |
| Vendor Product | CNCP09A1002BKAA |
| Conductor Type | Stranded Copper |
| Conductor Resistance | DC: 4.61 Ohm/km AC: 5.61 Ohm/km |
| Core Colours | Red/Black/Green/Yellow |
| Insulation Material | V-90 PVC |
| Insulation Thickness | 0.8 mm |
| Insulation Resistance | 12 MOhm/km |
| Overall Diameter | 13.9 mm x 6.3 mm |
| Product Type | Power Cable |
| Sheath Material | PVC |
| Sheath Thickness | 1.1 mm |
| Sheath Colour | Black |
| Standards | AS/NZS 1125 AS/NZS 5000.2 |
| Temperature | 90 deg C |
| Voltage | 450-750 Volt |
| Conductor Size | 4 mm |
| Number of Cores | 2 + Earth |
| Earth Conductor Size | 2.5 mm |
