Olex 16mm Orange Circular Cable Unarmoured V-90 PVC/PVC 1mtr

Description

Circular Cable Unarmoured, 16mm, Stranded Copper, 0.6-1 kV, 3 Core + Earth, 7/1.7mm Strands, 19.6mm Overall Diameter, 6mm Earth Conductor, 1 mtr Length, 78mm Bend Radius, 1mm Insulation Thickness, 1.8mm Sheath Thickness, AC: 1.4 Ohm/km Conductor Resistance, 8.4 MOhm/km Insulation Resistance, Red/Blue/White/Green/Yellow Core, V-90 PVC Insulation, PVC Sheath, Orange Sheath, 90 deg C, AS/NZS 1125 AS/NZS 5000 AS/NZS 5000.1 AS/NZS 5000.2

Key Specifications

Barcode (EAN-13)	99319215057216
SKU	OLX7/170-3ECA9
Brand	Olex
Product Type	Circular Cable Unarmoured

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	1
UNSPSC Class	26121600
UOM	MTR
Vendor Product	FNHP15AA003OMAA
Bend Radius	78 mm
Conductor Resistance	AC: 1.4 Ohm/km
Conductor Size	16 mm
Conductor Type	Stranded Copper
Core Colours	Red/Blue/White/Green/Yellow
Earth Conductor Size	6 mm
Insulation Material	V-90 PVC
Insulation Resistance	8.4 MOhm/km
Insulation Thickness	1 mm
Number of Cores	3 Core + Earth
Overall Diameter	19.6 mm
Sheath Material	PVC
Sheath Colour	Orange
Standards	AS/NZS 1125 AS/NZS 5000 AS/NZS 5000.1 AS/NZS 5000.2
Sheath Thickness	1.8 mm
Stranding	7/1.7 mm
Temperature	90 deg C
Voltage	0.6-1 kV
