Panduit Quick Connect Female Insulated Double Grip 4-6mm 6.3mm Tab Yellow Vinyl

$Panduit\Panduit_EDV10-250-Q.jpg$

Description

QC Terminal, Female, Insulated, Double Grip, Conductor Size: 4-6 mm, Tab Size: 6.3mm, Wire Strip Length: 7.1mm, Barrel Type: Grip Sleeve, 600 Volt Maximum, Crimping Die: CT-600-A, CT-1550, CT-1551, CT-2300/ST, CT-2500/L, Mounting Method: Free Hanging, Base Material: Copper, Conductive Material: Copper, Insulation Material: Vinyl, Yellow Insulation, Tin Plated Finish, 90 deg C, Max. Wire Insulation Diameter: 5.8mm, 26.2mm Length, 7.6mm Width, Height: 3.3mm, Thickness: 0.81mm, 25 Pack

Key Specifications

SKU	PANEDV10-250-Q
Brand	Panduit
Range Name	StrongHold
Product Type	Quick Connect Terminals

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	25
UNSPSC Class	39121400
UOM	EA
Vendor Product	EDV10-250-Q
Base Material	Copper
Conductive Material	Copper
Conductor Size	4.0-6.0mm
Crimping Die	CT-600-A CT-1550 CT-1551 CT-2300 / ST CT-2500 / L
Finish	Tin Plated
Height	3.3 mm
Insulation Colour	Yellow
Insulation Material	Vinyl
Mounting Method	Free Hanging
Pack Size	25 Pack
Tab Size	6.3 mm
Temperature	90 deg C
Thickness	0.81 mm
Voltage Rating	600 Volt
Width	7.6 mm
Wire Insulation Diameter	5.8 mm
Wire Strip Length	7.1 mm
