Panduit Ring Terminal Insulated Single Grip 4-6mm M4 Stud Yellow 26.7mm OAL

Description

Ring Terminal, Insulated, Single Grip, Conductor Size: 4-6 mm, Stud Size: M4, Terminal Type: Circular, 600 Volt Maximum, Wire Strip Length: 7.9mm, Barrel Type: Funnel, Seam Type: Butted, Mounting Method: Free Hanging, Body Material: Copper, Conductive Material: Copper, Insulation Material: Vinyl, Yellow Insulation, Tin Plated Finish, 221 deg F, 26.7mm Overall Length, 13.3mm Lug Length, 7.9mm Lug Width, 1mm Lug Thickness, 4.3mm Lug Inside Diameter, Barrel Length: 11.3mm, Max. Insulation Diameter: 5.8mm, 25 Pack

Key Specifications

SKU	PANEV10-8RB-Q
Brand	Panduit
Range Name	StrongHold
Product Type	Forked & Ring Terminals

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	25
UNSPSC Class	39121400
UOM	EA
Vendor Product	EV10-8RB-Q
Barrel Type	Funnel
Barrel Length	11.3 mm
Body Material	Copper
Conductive Material	Copper
Conductor Size	4.0-6.0mm
Finish	Tin Plated
Insulation Colour	Yellow
Insulation Diameter	5.8 mm
Insulation Material	Vinyl
Lug Inside Diameter	4.3 mm
Lug Length	13.3 mm
Lug Thickness	1 mm
Lug Width	7.9 mm
Mounting Method	Free Hanging
Overall Length	26.7 mm
Pack Size	25 Pack
Seam Type	Butted
Temperature	221 deg F
Stud Size	M4 Stud
Terminal Type	Circular
Voltage Rating	600 Volt
Wire Strip Length	7.9 mm
