Panduit Ring Terminal Insulated Double Grip 14mm M10 Stud Blue 44.7mm OAL

Description

Ring Terminal, Insulated, Double Grip, Conductor Size: 14 mm, Stud Size: M10, Terminal Type: Circular, 600 Volt Maximum, Wire Strip Length: 14.3mm, Barrel Type: Standard, Seam Type: Brazed, Crimping Die: KST-HDC38A, Mounting Method: Free Hanging, Body Material: Copper, Insulation Material: Vinyl, Blue Insulation, Tin Plated Finish, 221 deg F, 44.7mm Overall Length, 22.1mm Lug Length, 16mm Lug Width, 1.5mm Lug Thickness, 10.5mm Lug Inside Diameter, Barrel Length: 11.3mm, Max. Insulation Diameter: 10.1mm, 25 Pack

Key Specifications

SKU	PANEV6-38R-Q
Brand	Panduit
Range Name	StrongHold
Product Type	Forked & Ring Terminals

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	25
UNSPSC Class	39121400
UOM	EA
Vendor Product	EV6-38R-Q
Barrel Type	Standard
Barrel Length	11.3 mm
Body Material	Copper
Conductor Size	14mm
Crimping Die	KST-HDC38A
Finish	Tin Plated
Insulation Colour	Blue
Insulation Diameter	10.1 mm
Insulation Material	Vinyl
Lug Inside Diameter	10.5 mm
Lug Length	22.1 mm
Lug Thickness	1.5 mm
Lug Width	16 mm
Mounting Method	Free Hanging
Overall Length	44.7 mm
Pack Size	25 Pack
Seam Type	Brazed
Temperature	221 deg F
Stud Size	M10 Stud
Terminal Type	Circular
Voltage Rating	600 Volt
Wire Strip Length	14.3 mm
