Redback Horn Speaker 10W 100V EWIS IP66 AS ISO7240.24 Fire PA Grey

chevron-left
loader
Loading...

Description

chevron-down
Designed to meet AS ISO7240.24:2018. A One-Shot horn speaker designed to save installers time and money. Typically to terminate cabling internally on a horn speaker it involves removing three screws on the rear cover, connecting the cable and then re-installing the same screws.. The One-Shot horn is primarily used for fire and evacuation systems where a high degree of speech articulation and program clarity is paramount. Typical applications include schools, train and bus stations, airports, car parks and plant rooms.

Key Specifications

chevron-down
Barcode (EAN-13)
9321758227695
SKU
RDBCF2050G
Brand
Redback
Product Type
Speakers

Technical Specifications

chevron-down
Looking for something specific? Search with keywords to help filter your required specifications.
search close

Additional Information

Features
  • Designed to meet AS ISO7240.24:2018 for fire/evac installations
  • Requires no external EQ for AS ISO7240.24:2018 fire systems
  • Twist lock cap reduces installation time
  • UV stabilised ABS construction
  • Excellent sound dispersion
  • IP66 rated for weather resistance
  • EWIS line monitoring system compatible
  • Two cable glands supplied for loop in, loop out wiring
  • Stainless steel mounting hardware
  • 5 Years warranty
Standard Pack Size 8
UNSPSC Class 46191500
UOM EA
Vendor Product CF2050G
Colour Grey
Coverage Horizontal: 1000Hz: 120 deg Vertical: 1000Hz: 130 deg
Dimensions 244 mm Length x 167 mm Width x 150 mm Height
Material Flame Retardant ABS
Frequency Horizontal & Vertical: 100 Hz - 12.5 KHz 500 Hz - 6.3 KHz +/-5dB
Mounting Method Wall
Sound Level Horizontal 112 dB (10W at 1 mtr) Vertical 112 dB (10W at 1 mtr)
Temperature -20 to 55 deg C
Voltage 100 Volt
