Sprecher+Schuh Non-Reversing Contactor 3 Pole 55kW 116A AC3 160A AC1 100-250VAC/DC 1NO-1NC Auxiliary Electronic

$Sprecher\Sprecher_CA9-116.jpg$

Description

Non-Reversing Contactor, 100-250 Volt AC/DC Coil Voltage, 1 Normally Opened/1 Normally Closed Aux Configuration, 55 kW AC3 AC3 Rating, 46/116/65 Amp AC3 AC3 Rating, 160 Amp AC1 AC1 Rating, 3 Pole, 20-55 ms Closing/40-70 ms Opening Operating Time, Bolt Terminal, Screw Mounting, 150 mm Height, 90 mm Width, 126 mm Depth, Without PLC Interface Electronic Coil

Key Specifications

SKU	S&SCA911611120W
Brand	Sprecher+Schuh
Range Name	CA9
Product Type	Contactors Non-Reversing

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Simplifies selection with electronic wide range AC/DC coils Saves energy with low power consumption For ease of change over, adaptor plates available in KIT form for CA6 to CA9 migration Several contactor families provide a wide variety of contactor sizes, offering economy and selection Compact dimensions saves panel space
Standard Pack Size	1
UNSPSC Class	39121500
UOM	EA
Vendor Product	CA911611120W
AC1 Rating (Amps)	160 Amp AC1
AC3 Rating (Amps)	46/116/65 Amp AC3
AC3 Rating (kW)	55 kW AC3
Contact Configuration	1 Normally Opened & 1 Normally Closed Aux
Depth	126 mm
Height	150 mm
Mounting Method	Screw
Number Of Poles	3 Pole
Operating Coil Voltage	100-250 Volt AC/DC
Operating Time	20-55 ms Closing/40-70 ms Opening
Please Note	Without PLC Interface Electronic Coil
Terminal Connection	Bolt
Width	90 mm
