Sprecher+Schuh Auxiliary Contact Block Front Mount Standard 4 Pole 4NO

$Sprecher\Sprecher_CS7PV40.jpg$

Description

Auxiliary Contact Block Standard, 690 Volt Operational Voltage, 10 Amp Operational Current, 4 Normally Opened Configuration, 4 Pole, Front/Top Mounting, For Use With CA7 Contactors and CS7 Control Relays

Key Specifications

Barcode (EAN-13)	9321807146069
SKU	S&SCS7-PV-40
Brand	Sprecher+Schuh
Range Name	CA7/CS7

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Several contactor families provide a wide variety of contactor sizes, offering economy and selection Compact dimensions saves panel space Bifurcated auxiliary contacts provides a higher degree of reliability than the standard cross-stamped auxiliary contacts because it H-bridge divides each movable contact into two sections at the tip of the spanner Typical application is low-voltage low-current applications (that is PLC) Cross-stamped contacts are good for a minimum of 5 mA at 17 volt while bifurcated contacts are good for a minimum of 3 mA at 5 volt
Standard Pack Size	1
UNSPSC Class	39121500
UOM	EA
Vendor Product	CS7PV40
For Use With	CA7 Contactors and CS7 Control Relays
Contact Configuration	4 Normally Opened
Mounting Method	Front/Top
Number Of Poles	4 Pole
Operational Current	10 Amp
Operational Voltage	690 Volt
